AxCIS
Contact Image Sensor (CIS)
High-speed and high-resolution line scan in a fully integrated, compact package
AxCIS™ is a compact, fully integrated line-scan imaging module that combines sensors, lenses, and lighting in one solution. It delivers up to 120 kHz mono or 60 kHz × 3 color line rates with 900 dpi resolution for precise, high-speed print defect detection. Its unique staggered design covers the entire field of view without missing pixels, ensuring a seamless image without interpolation. Ideal for space-constrained installations, AxCIS mounts easily without alignment or calibration, operates on a single 24 V supply, and includes HDR for reflective materials.
Combining Sensors, Lenses and Lighting All-in-one
Line Scanning for Improved Quality
From paper to cardboard, plastic or metal, in continuous webs or sheets, print inspection applications are well suited to line scan systems.
| AVAILABLE MODELS | ||||||
| Color 400 mm AX-FC-04B06T-00 |
Mono 400 mm AX-FC-04B12H-00 |
Color 600 mm AX-FC-06B06T-00 |
Color 800 mm AX-FC-08B06T-00 |
Mono 800 mm AX-FC-08B12H-00 |
||
|
AxCIS SPECIFICATIONS
|
Resolution | 14304 × 3 | 14304 × 2 | 21440 × 3 | 28603 × 3 | 28603 × 2 |
| Spectrum | Color | Mono | Color | Color | Mono | |
| Interface | Camera Link HS | Camera Link HS | Camera Link HS | Camera Link HS | Camera Link HS | |
| Pixel Size | 28 µm | 28 µm | 28 µm | 28 µm | 28 µm | |
| Max Line Rate | 60 kHz × 3 | 120 kHz | 60 kHz × 3 | 60 kHz × 3 | 120 kHz | |
Contact Image Sensors Explained
What is a Contact Image Sensor?
CIS vs Conventional Line Scan Cameras
How Does A Contact Image Sensor Work?
What Value Does a CIS Provide?
What is Working Distance and Depth of Field?
Integrate the Future of Line Scan Imaging
Ready to see how the AxCIS can elevate your inspection process? Complete the form to get detailed specifications, pricing information, and a consultation with one of our imaging experts.
